HTV挤出型內纤外胶扩张管 ULTRAFLEX

主要特性 Key properties

•  Long-term heat resistance of -60°C to +250°C
• 长期工作温度-60°C to +250°C
• Short-term heat resistance up to +400°C
• 短期耐温可达+400°C
• Electrical strength > 2,50kV~10.0KV
• 耐击穿电压：> 2,50kV~10.0KV
• Self-extinguishing (UL 94V0 or UL1441 VW-1) is possible
• 可根据需要做自熄款，按照UL 94V0 or UL1441 VW-1标准
• Extensible in diameter by up to 100%
• 内径可以扩大100%。
• Good flexibility and tensibility
• 柔软，拉力强
• Huge colour range
• 大部分颜色都可以做
• Nominal diameter 4 mm to 60.0 mm
• 内径尺寸 4 mm 到 60.0 mm
• Physiologically harmless
• 环保，环保，无害，无毒
• Equal surface because of silicone coating for an easy cable assembly
• 表面硅胶附着使得管子柔软利于线束穿管组装

产品描述 Product description

ULTRAFLEX保护套管是由特殊编织结构和高质量硅胶制成的内部纺织玻璃套管的组合产品。特殊的编结结构确保高径向弹性高达100%，而开口不会散口。这满足了线束组装的要求。它具有很高的耐高温和腐蚀性介质。ULTRAFLEX保护套管也有不同的颜色可供选择。可以根据UL 1441 VW-1或UL 94-V0阻燃要求生产。

The ULTRAFLEX protective sleeve is a combination of an inner textile glass sleeve made out of a special plaited construction and a high-quality silicone coating. The special plaited construction ensures a high radial elasticity of up to 100% without the ends fanning out. This fulfils the cable assembly requirements. It has high resistance to high temperatures and aggressive media. The ULTRAFLEX protective sleeve is also available in different colours. Also a special setting for a self-extinguishing version according to UL 1441 VW-1 or UL 94-V0 is possible.
